Chinese SR 35
Precision steering control through direct-drive, the SR 35 is a lightweight and compact steering robot.
Product overview
The SR 35 uses a lighter, thinner version of the SR 60 motor to provide ample performance for typical driving scenarios and vehicle dynamics tests. It has the lowest combination of rotational inertia and motor bearing friction of our range, making it a popular choice for Lateral Support Systems (LSS) testing.
Specifications
The SR 35 is a lightweight and compact steering robot that a direct drive motor that can deliver up to 43 Nm of torque and 2500°/s of velocity.
SR 35 Steering Robot
Direct drive motor
Yes
Hollow for use with airbag in place
No
Suitable for sine-dwell/fishhook
No
Max torque (short duration)
43 Nm at 850°/s
Rated torque
35 Nm at 1300°/s
Max velocity
2500°/s at up to 5 Nm
Motor weight
9 kg
Adaptable for heavy vehicle testing
No
