Chinese PinPoint
The ultra-compact GNSS motion pack for vehicle testing.
Product overview
The PinPoint is a GNSS motion pack that measures the position and movement of vehicles with high accuracy. The ultimate motion pack for vehicle testing, PinPoint combines the best of OxTS technology with AB Dynamics’ expertise and innovation. Offering 2 cm position accuracy thanks to quad constellation GNSS receivers and high-performance inertial sensors, PinPoint facilitates swift and precise measurements for a variety of vehicle tests including driverless durability and misuse, ADAS and NCAP testing.
PinPoint’s compact size and light weight allow for easy installation in vehicles, enhancing flexibility and usability during testing. The device’s compatibility with our driving robots and ADAS platforms ensures seamless integration and synchronisation, helping to streamline the testing process. With ethernet and optional CAN outputs, PinPoint has the connectivity and interfaces to accommodate diverse ADAS testing requirements.
Specifications
PinPoint is a single-box navigation solution, perfect to use with our driving robots, ADAS platforms and Path Following software.
Dimensions and performance
Size
142 x 77 x 41 mm
Weight
0.435 kg
Environmental protection
IP65
Position accuracy (RTK)*
0.02 m
GNSS
GPS L1, L2C
GLONASS L1, L2
BeiDou B1, B2
Galileo E1, E5
GLONASS L1, L2
BeiDou B1, B2
Galileo E1, E5
Ethernet
10/100 Base-T with AB Dynamics interface
CAN (optional)
Up to 1Mbit/s
